MT1095 can be directly mounted onto the standard USB port of the host devices. No driver is needed, as MT1095 simply works as a USB HID keyboard, it is compatible with most host devices and operating systems including Mac®, Android®, and Windows®. MT8495 also comes with a USB extension cable that provides more flexibility for barcode scanning tasks.
More info link website: https://www.marsonscan.com/products-detail/MT1095_1D_USB_Scanner/
Built with a Marson high-performance mini scan engine, MT1095 has optimal scanning efficiency and accuracy with a scanning width of 14cm and reading distance from 4cm to 23cm on commodity barcodes ensuring barcodes can be easily read within 1/10 of a second. MT1095 supports high-density barcode up to 4mil (0.1mm).
With auto-adaptive high-speed scanning at a maximum of 650 scans per second based on environment lighting, MT1095 easily captures any barcodes on either printed paper or the LCD screen of smartphone or tablet. MT1095 is also capable of reading barcodes under ambient light conditions from complete darkness to direct sunlight making it possible to operate in both indoor and outdoor applications.
As classified by Photo-biological Safety Standard EN/IEC 62471, the light source of MT1095 is completely safe for human eyes even after long hours of operation. With built-in buzzer and user-friendly trigger button, MT1095 provides an instinctive and better user experience. MT1095 is also easily configured on the host computer by Marson's free user-friendly software tool, Ez Utility®.
| Light Source | 625nm visible red LED |
| Sensor | Linear Image Sensor |
| Scan Rate | 650 Scans/Sec |
| Resolution | 4Mil/ 0.1mm |
| Scan Angle | 41° |
| Print Contrast | 30% |
| Width of Field | 140mm (13Mil Code39) |
| D.O.F (@ 800 Lux) |
|
| Dimension | W19 x L41.8 x H12.5 mm |
| Weight | 10g |
| Color | Black |
| Material | PC |
| Connector | USB Type A |
| Cable | 1.8M (USB extension cable) |
| Trigger | Scan Button |
| Indicator | LED, Buzzer |
| Operation Voltage | 5 VDC ± 5% |
| Working Current | < 115mA |
| Standby Current | < 60mA |
| Interface/ Profile |
|
| Operating Temperature | 0 ~ 50˚C |
| Storage Temperature | -20 ~ 60˚C |
| Humidity | 0% ~ 95%RH (Non-condensing) |
| Drop Durability | 1.5M |
| Ambient Light | 100,000 Lux (Sunlight) |
| 1D Symbologies | UPC-A/UPC-E, EAN-8/EAN-13, Industrial 2 of 5, Codabar, Matrix 2 of 5, Code 11, Code 93, Code 32, Code 128, Standard Code 39, Full ASCII Code 39, Interleaved 2 of 5, China Postal Code, MSI Plessy Code, UK Plessy Code, EAN/UCC 128, Telepen Code, IATA Code, GS1 Databar |
| ESD | Functional after 4KV contact, 8KV Air discharge |
| EMC | FCC Part 15B Class B, CE EN55022/24 |
| Safety Approval | EN/IEC62471 (Exempt Group) |
| Environmental | WEEE, RoHS 2.0 |
| Cable | USB A(F) to USB A(M) Cable, 1.8M, Black (P/N: 7005-9297A50, QTY: 1) |
| Taiwan | M 395218 M 411624 |
| China | ZL 201020287072.6 ZL 201120123585.8 |
| United States | US 8,220,712 B2 |
| Japan | 3169218 |
| Germany | 202011050029.2 |
