MT10 Scan Engine is designed for 1D mini high performance scanning and simple integration. With its very small size and 3.3V low power consumption, MT10 is ideal for all 1D barcode applications of mobile devices where space is limited and power consumption is critical, such as smartphone, tablet PC, industrial PDA, and wearable devices. It is ideal for a wide range of applications including field service, healthcare, mobile POS, access control and inventory management.
。650sps / Middle Range / Small Size / UART / USB
。Small profile and lightweight.
。Read all major 1D barcodes.
。Fits into constrained space.
Discover more: https://www.marsonscan.com/products-detail/MT10_1D_Mini_Scan_Engine/
MT10 is the smallest and lightest 1D barcode scan engine in its class. With extraordinarily small size of W14 x L11.9 x H7 mm and the weight of only 1 gram, MT10 can fit into the most space-constrained product and is also capable of being mounted from top or bottom, thus providing unparalleled flexibility for product design.
MT10, with enhanced optical design and latest decode algorithm, virtually scans all 1D barcodes on any surface, either paper-based label or mobile phone display. With MT10 integrated into mobile device, users may expand their business into many new applications such as eCoupon, eTicket, Digital ID cards and mobile payments.
MT10 enhances design flexibility by offering various output interfaces with USB HID,USB VCP and UART and enabling the user to easily configure the reading modes and scanner settings according to preference. The flash memory of MT10 serves as a flexible and upgradeable provision for additional requirements or performance enhancement and extends the product's lifecycle as well.
MT10 automatically adjusts its parameters for optimal scanning performance which provides the freedom to scan barcodes from under complete darkness to direct sunlight. With configurable scan rate between auto-adaptive mode and fixed mode, MT10 is ideal for both high-speed scanning applications and smart devices which require more motion tolerance and ambient light immunity.
A set of commands is supported to enable the host device to configure all the functions of MT10 thereby fulfilling dynamic configurations demand. To help user grasp and understand the bi-directional communication more quickly, the Windows®-based BEO® configuration utility is provided as a user-friendly platform where testing MT10 can be done in a much easier way.
MB100 Demo Kit (sold separately) provides the software and hardware tools required for testing MT10 before integrating it into the host device. The kit contains software utility, interface cables and MB100 Multi I/O board. Due to its small size, MB100 is also suitable for being installed inside the host system as an interface board connecting MT10 to the host device.
| Light Source | 625nm visible red LED |
| Sensor | Linear Image Sensor |
| Scan Rate | 650 Scans/ sec |
| Resolution | 4Mil/ 0.1mm |
| Scan Angle | 41° |
| Print Contrast | 30% |
| Width of Field | 140mm (13Mil Code39) |
| D.O.F (@ 800 Lux) |
|
| Dimension | W14 x L11.9 x H7 mm |
| Weight | 1g |
| Color | Black |
| Material | PC |
| Connector | 13pin ZIF (pitch=0.3mm) |
| Cable | 13-pin to 12-pin FPC cable (pitch=0.5mm) |
| Operation Voltage | 3.3VDC±5% |
| Working Current | < 85mA (USB); < 75mA (UART) |
| Standby Current | < 45mA (USB); < 35mA (UART) |
| Idle Current (Sleep Mode) | < 500uA (USB); < 300uA (UART) |
| Interface/ Profile |
|
| Operating Temperature | 0 ~ 50°C |
| Storage Temperature | -20 ~ 60°C |
| Humidity | 0% ~ 95%RH (Non-condensing) |
| Drop Durability | 1.5M |
| Ambient Light | 100,000 Lux (Sunlight) |
| 1D Symbologies | UPC-A/UPC-E, EAN-8/EAN-13, Industrial 2 of 5, Codabar, Matrix 2 of 5, Code 11, Code 93, Code 32, Code 128, Standard Code 39, Full ASCII Code 39, Interleaved 2 of 5, China Postal Code, MSI Plessy Code, UK Plessy Code, EAN/UCC 128, Telepen Code, IATA Code, GS1 Databar |
| ESD | Functional after 4KV contact, 8KV Air discharge (requires housing that is designed for ESD protection and stray from electric fields) |
| EMC | FCC Part 15B Class B, CE EN55022/24/32 |
| Safety Approval | EN/IEC62471 (Exempt Group) |
| Environmental | WEEE, RoHS 2.0 |
| Cable | 13-pin to 12-pin FPC cable, 50mm, Brown (P/N: 6351-0501113, QTY: 1) |
| Screw | Tapping Screw, T1.7x4mm (P/N: 4235-1704X51, QTY: 2) |
